FLIR Quasar Gen III User And Installation Manual page 63

Detection Type
In the text box, enter the IP address to ping and the time interval (in minutes) between pings. Click SAVE
after configuring the settings.
Triggered Action
The Administrator can specify various alarm actions to take when an alarm is triggered. See the
for a detailed description of the actions. The following options are available:
·
Enable alarm output
to enable alarm relay when a network failure is detected.
·
Enable alarm output
to enable alarm relay when a network failure is detected.
·
Send message by FTP – Select whether to send an alarm message by FTP when a network
failure is detected.
·
Send message by E-Mail – Select whether to send an alarm message by e-mail when a network
failure is detected.
·
Record video clip – Select this box in order to save the alarm-triggered recording into an SD or
microSDXC card.
Click SAVE to save the network failure detection settings.
9.3.4.3 Periodic Event
The Periodic Event screen is used to specify an alarm to be triggered at a specified time interval.
Periodic Event
Select Off or On to activate this function. The default is Off.
Time Interval
In the Minimum interval text box, enter the number of seconds for the minimum interval between alarms.
The range is from 20 to 3600 seconds. The default is 60.
Triggered Action
The Administrator can specify various alarm actions to take when an alarm is triggered. See the
for a detailed description of the actions. The following options are available:
·
Upload Image by FTP – Selecting this option enables you to assign an FTP site and configure
various parameters.
·
Upload Image by E-Mail – Selecting this option enables you to assign an e-mail address and
configure various parameters.
September 7, 2017
1
– Check this box and select the predefined type of alarm output (low or high)
2
– Check this box and select the predefined type of alarm output (low or high)
Periodic Event Screen
CP-6302 User and Installation Guide
Configuration and Operation
IO section
IO section
57
