6. Right-click the mouse and select the assigned IP address or click the Assign IP button to
open the DNA Assign IP dialog box.
Note:
The camera default IP Address and the subnet mask IP Address are automatically
supplied by the DHCP server.
7. In the dialog box that is displayed, enter values for the IP Address, Gateway and Netmask .
8. Click Update and wait for
9. Disconnect the Ethernet cable. The camera is ready for deployment (mounting) in a site installation.
Note:
1. The camera can be connected to a PC for bench installation via an Ethernet cross-cable.
2. The camera default IP Address is automatically set by the DHCP server. If using
Latitude, the Address must be set manually.
Tip:
A camera setup adapter, such as Veracity Pinpoint, can be used to connect a laptop directly to
the camera when using PoE++.
September 7, 2017
OK status to be displayed.
DNA Assign IP Dialog Box
CP-6302 User and Installation Guide
Installation
19
