Configuration and Operation
2. From the Resolution drop-down menu, select the desired resolution. A maximum 25/30 frames per
seconds is available when selecting WDR 2 Shutter (PAL) or WDR 2 Shutter (NTSC). A maximum
50/60 frames per second is available when selecting 50 fps (PAL) or 60 fps (NTSC). The default
setting is 1920 x 1080.
3. From the Rate Control drop-down menu, select CBR, VBR, or LBR. The default setting is VBR.
·
CBR (Constant Bit Rate) is used for setting a constant, maximum bit rate.
CBR is not optimal for storage or quality, because it does not allocate enough
data for complex sections (which results in degraded quality), and wastes
data on simple sections. Choosing a higher bit rate results in better quality,
but requires more storage.
·
VBR (Variable Bit Rate) files vary the amount of data per time segment. VBR
enables a higher bit rate (and therefore requires more storage space) for more
complex video or audio, while a lower bit rate and less storage space is
allocated to less complex media. VBR files may take longer to encode and
might be more problematic for streaming if the maximum bit rate is not set
high enough to allow for high instantaneous bit rates.
·
LBR (Low Bit Rate) encoding is used primarily for speech at rates below 4kbps. With this
encoding, not all of the voice frequency range is encoded. LBR consumes less storage
space than CBR or VBR.
4. From the Profile drop-down menu, select the H.265 Profile.
·
High Profile (HP) provides the best trade-off between storage size and video latency and is
the primary profile for HD broadcast applications. It can save 10-30% of the storage cost
over Main Profile. However, it may also increase video latency, depending on the stream
structure.
·
Main Profile (MP) is the default setting. It provides improved picture quality at reduced
bandwidths and storage costs.
5. Move the Frame Rate slider to the desired setting. The setting range of the MJPEG frame rate is
from 1 to 30 (default setting) in NTSC and 1 to 25 (default setting) in PAL. The higher the frame rate,
the smoother the motion in the video.
6. Move the Bit Rate slider to the desired setting between 1-10240. The default setting is 4096. The
higher the bit rate, the better the image quality. Set the maximum bit rate high enough to allow for a
high instantaneous bit for more complex video. A higher bit rate consumes more storage space.
80
H.265-Only
Stream
1920 x 1080
1280 x 1024
1280 x 720
1024 x 768
800 x 600
720 x 480 (NTSC)
720 x 576 (PAL)
640 x 480
CP-6302 User and Installation Guide
BNC Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
