The interface is shown as in Figure 5-90. Here you can see HDD information. You can
also operate the read-only, read-write, redundancy (if there are more than on HDD) and
format operation.
5.8.4.3 Manual Record
The interface is shown as in Figure 5-91.
Please refer to the following sheet for detailed information.
Parameter Function
Here you can view channel number.
Channel
The number displayed here is the max channel amount of your
device.
Status There are three statuses: schedule, manual and stop.
System enables auto record function as you set in record schedule
Schedule
setup (general, motion detect and alarm).
Figure 5-90
Figure 5-91
