Series - Optiview HDVR4/8/16-Q2 User Manual

SN Icon
10 HDMI1
11 HDMI2
12 VGA
13
14 VIDEO IN
15
16
17
The 32-channel 5-Way4-HDD 720P 1.5U rear panel is shown as below. See Figure 2-86.
Please refer to the following sheet for detailed information.
SN Icon
1 MIC OUT
Name
High Definition
Media Interface 1
High Definition
Media Interface 2
VGA video output
port
Network port
Video input port
Power switch
Power socket
Ground terminal
Figure 2-86
Name
Audio output port
Note
High definition audio and video
signal output port. It outputs the
same video source as VGA/TV.
Support mouse operation
control.
High definition audio and video
signal output port. Support multiple-
window video
output. Support tour function.
VGA video output port. Output
analog video signal. Can connect to
the monitor to view ananlog video
output.
1000Mbps Ethernet port
Connect to analog camera, video
input signal.
Power on/off button.
Power socket
Ground
Note
Audio output port. It is to output the
analog audio signal to the devices
such as the sound box.
and
matrix
28
