Optiview HDVR4/8/16-Q2 User Manual page 289

Please refer to the following sheet for detailed information.
Parameter Function
There are four options: 1920×1080,1280 × 1024(default),1280 ×
Resolution
720,1024×768. Please note the system needs to reboot to activate
current setup.
Transparency Here is for you to adjust transparency. The value ranges from 128
to 255.
Check the box here, you can view system time and channel
Time
number on the monitor video.
title/channel
title
Check the box; you can optimize the margin of the preview video.
enhance
5.8.5.2.2 TV Adjust
Note
This function is for some series product only.
It is to set TV output region. See Figure 5-96.
5.8.5.2.3 Tour
The tour interface is shown as in Figure 5-97. Here you can set tour interval, split mode,
motion detect tour and alarm tour mode.
Figure 5-96
