Select a channel group and then click
Modify channel group
Select a channel group and then double click, you can see the following interface. See
Figure 5-101. You can change the setup and then click OK button.
Adjust channel group sequence.
Click or to change channel sequence.
5.8.5.4 RS232
The RS232 interface is shown as in Figure 5-102.
Please refer to the following sheet for detailed information.
Parameter Function
Select the corresponding dome protocol.
Protocol
Default setup is console.
Select the baud rate.
Baud Rate
Default setup is 115200.
Data Bit The value ranges from 5 to 8.
Default setup is 8.
There are two options: 1/2.
Stop bit
Default setup is 1.
Parity There are five options: none/odd/even/space/mark.
,you can delete it.
Figure 5-101
Figure 5-102
