Invasive blood pressure functions
Temperature functions
4-24
Maintenance and checkout: Checkout procedure
1. Set up simulator:
Go to BP functions, select BP1, then 0.
Set output to 0 mmHg.
2. Connect the IP simulator cable from the BP1 connector of the
simulator to the corresponding IP connection of the acquisition
device.
3. Observe an ART1 label and graticules on the patient monitor.
4. Zero the ART1 waveform by pressing the Zero All button on the
Patient Data Module, Solar keypad or remote.
5. Set the simulator to output 240 mmHg. (BP1 > STAT > UP > RUN)
6. Observe a reading of 240 ± 4 mmHg on the patient monitor.
7. Set the simulator to BP dynamic waveform output. (BP1 > DYNA >
RUN)
8. Set the patient monitor ART1 SCALES to AUTO.
9. Observe a distortion-free waveform and a blood pressure reading of
approximately 120/80 (93) on the patient monitor.
10. Repeat these tests with each IP/BP connector selecting BP2, BP3,
etc.
NOTE
Use the Dual IP Adapter Cable to test the third and fourth IP
functionality for each IP/BP connection.
1. Go to TEMP functions on the simulator and set a 37°C temperature
output.
2. Connect a temperature sensor adaptor to the TEMP/CO connector of
the acquisition device.
3. Set the switch on the adaptor to the 400 position.
4. Connect the temperature simulator cable from the temperature
output connector of simulator to the T1 connector of the temperature
sensor adaptor.
5. Observe that the T1 reading on the patient monitor is between 36.6
and 37.4.
6. Move the cable from the T1 connector of the temperature sensor
adaptor to the T2 connector.
7. Observe that the T2 reading appears on the patient monitor is
between 36.6 and 37.4.
8. Disconnect the temperature sensor adaptor and temperature cable
from the acquisition device and the simulator.
