Solar 8000M/i patient monitor

Due to continual product innovation, specifications and standards are subject to change without notice. The
following specifications are accurate as of the date of this publication, and pertain to Solar 8000M/i patient
monitor.
Specifications are based on a complete system including a 15 inch monitor (display*).
Performance specifications
Solar 8000M/i processing unit controls
Optional keypad with Trim Knob control and 18 active hard keys. See Keypad for applications and specifications.
Optional remote control with Trim Knob control and 18 active hard keys. See Remote Control for applications and specifications.
Optional touchscreen interface:
Communications protocols:
TRAM-NET
Unity
Processing
Main processor:
Graphics processor:
TRAM-NET communication processor:
LAN communication processor:
Alarms
Classification:
Patient Status Alarms — 4 levels:
System Status Alarms — 2 levels:
Notification:
Display of alarm information:
Continuous display of limits:
Interfaces
Contact your local sales representative.
Environmental specifications
Power requirements:
Power consumption:
Low-voltage shutdown:
Cooling:
Heat dissipation:
A-2
Appendix A – Technical specifications: Solar 8000M/i patient monitor
Requires touchscreen display and software.
Proprietary CSMA/CD protocol at 921 Kbits/sec
Ethernet IEEE 802.3 10 BASE T LAN
Motorola
Silicon MotionGraphics Accelerator with Silicon Image Transmitter providing
images on VGA and DFP displays
Within Motorola MPC860P (PowerPC), 66 MHz, 32 bit
Within Motorola MPC860P (PowerPC), 66 MHz, 32 bit
Crisis, Warning, Advisory, and Message
Warning and Advisory
Audible and visual, dependent on alarm level
All limits are viewable and printable
All parameters, one set of limits
110 ±20 VAC, 50/60 Hz, single phase
230 ±40 VAC, 50/60 Hz, single phase
100 Watts
<90 VAC/<190 VAC
Natural convection
341 Btu/hr
Solar 8000M/i patient monitor
®
MPC860P (PowerPC), 66 MHz, 32 bit
