Capnostat mainstream CO
Performance specifications
Information displayed:
Measurement range:
Accuracy:
Display resolution:
Respiration rate accuracy:
Rise time
CO2 rise time:
Compensations
O2/N2O compensation:
Barometric pressure compensation:
Technology
Sensor:
Calibration:
Alarms
Type:
CO2:
Respiratory rate:
Temporary silence:
Reset:
Cable length:
Construction:
Shock resistance:
Airway adapters
Adult:
Low volume:
A-16
Appendix A – Technical specifications: Capnostat mainstream CO
Inspired and expired CO2 concentrations in %, mmHg or kPa; respiratory rate,
continuous CO2 waveform
Pi CO2/Fi CO2: 0 to 100 Torr / 0 to 13%
Pe CO2/Fe CO2: 0 to 100 Torr / 0 to 13%
RR: 0 to 120 breaths/min
CO2 sensor accuracy: 0 to 40 mmHg ±2 mmHg; 41 to 100 mmHg 5% of reading
1 mmHg
±1 breath/min
Less than 60 msec
Operator selectable
Manual as set in monitor
Mainstream non-dispersive infrared (NDIR) absorption, dual wavelength ratiometric-true
single beam optics
Simple one-step calibration (less than 20 seconds); no calibration gases required.
As set in monitor
High inspired CO2; high/low expired CO2
Adjustable high and low
No breath detection system
On screen obstruction alarm
60 sec
Automatic
10 feet (3.04 m)
Durable high performance plastic sensor with flexible cable
Sensor designed to withstand 6-foot (2 m) drops to a tile surface
Reusable adult airway adapter, less than 5 cc dead space (pn 412341-001)
Reusable airway adapter, less than 0.5 cc deadspace (pn 412342-001)
Solar 8000M/i patient monitor
module
2
module
2
2026265-075C
