Set graph locations

Communication confirmation
Problems?
2026265-075C
Configuration: Configuring a patient monitor
Access MANUAL GRAPH LOCATION option, starting from the MAIN
menu.
1. Select MORE MENUS > MONITOR SETUP > GRAPH SETUP >
GRAPH LOCATION > MANUAL GRAPH LOCATION.
2. Using the TRIM KNOB control, choose the manual graph location
from the list.
3. Select ALARM GRAPH LOCATION.
4. Using the TRIM KNOB control, choose the alarm graph location
from the list.
5. Select PRINT WINDOW LOCATION.
6. Using the TRIM KNOB control, choose the print window location
from the list.
7. Select 12 LEAD PRINT LOCATION.
8. Using the TRIM KNOB control, choose the 12 lead print location
from the list.
Confirm communication across the network.
1. Admit and generate a waveform at the monitor with a simulator.
2. Press Graph Go/Stop and observe graph output at chosen locations.
If the writer or printer does not graph:
Ensure the writer or printer is turned on.
Check all cables for a good connection.
Check programmed alarms and manual graph locations at the
monitor.
If you do not have a waveform at the central station:
Ensure the central station software is compatible.
Check all cables for a good connection.
Check the programmed alarms and manual graph locations at the
monitor.
Ensure the care unit name is the same in the monitor and in the
central station.
Ensure the central station serial number and LAN address are
programmed correctly.
