Switch Installation
Step 3
Slide the retainer through the first latch.
Figure 51: Sliding the Retainer Through the Latch (5RU 19" Rack Mount Chassis)
Figure 52: Sliding the Retainer Through the Latch (Flexible mount with IEC C14 power junction box)
1
2
AC power cord
Smaller sleeve for thin power cords
3
Latch
Catalyst Digital Building Series Switch Hardware Installation Guide
Installing the Power Cord Retainer
77
