Vertical Mounting; Fixed Vertical Mount - Cisco CDB-8U Installation Manual

Flexible Mounting
Warning
Figure 23: Inserting switch into flexible mount assembly

Vertical Mounting

Vertical Mounting can be done in two different positions:

Fixed Vertical Mount

To install a Catalyst Digital Building Series Switch in a flexible mount in fixed vertical mounting orientation,
follow these steps :
If you are using the flexible mount with a direct-wired junction box (CDB-MNT-FLEX-DIR), refer to the
Note
Electrical Installation
Before You Begin
• Refer to
• Refer to
(CDB-MNT-FLEX-DIR).
Catalyst Digital Building Series Switch Hardware Installation Guide
36
Switches require at least 3 inches of space above the heatsink fins for proper cooling. Do not
stack multiple switches on top of each other in horizontal mounting orientation. To collocate
multiple switches, use top vertical mounting orientation as described in
section before you start the installation procedure.
Installation Guidelines section.
Electrical Installation section if you are using the flexible mount with direct-wired junction box
Switch Installation
Top Vertical Mount .
