Flexible Mounting
Flexible mount with direct-wired junction box
Figure 11: Flexible mount with direct-wired junction box - Front view
Figure 12: Flexible mount with direct-wired junction box - Rear view
1
2
3
The mounting procedure includes two types of installations :
Catalyst Digital Building Series Switch Hardware Installation Guide
22
Direct-wired junction box
1/2" knockout
3/4" knockout
Switch Installation
