LEDs

Speed LED

Color
Off
Green

Power Save LED

Color
Off
Green

Mode Button

The mode button is used for resetting the switch, entering express setup mode, selecting or changing an LED
mode, and manually waking up the switch from hibernation mode.
In Cisco Catalyst Digital Building series switches, LEDs are normally turned off to save power. When the
mode button is pressed, the LEDs turn on for a set period (60 seconds) before they turn off again to save
power. This can be overridden by a configuration parameter which alters the default 60 second timeout or
disables LED power savings completely. All LEDs are affected by this function except the System LED,
which only dims and does not turn off completely.
System State
LEDs Off
LEDs On
Bootloader Active
Catalyst Digital Building Series Switch Hardware Installation Guide
10
Description
Speed Mode Disabled.
Speed Mode Active. Port LEDs indicate port speed as follows:
• Downlink: Green = 100 Mbps, Amber = 10 Mbps, Off = No Link
• Uplink: Green = 1000 Mbps, Amber = 100 Mbps, Off = 10 Mbps or No Link
Description
System is running normally
System is in a deep sleep mode.
Duration
Any
Any
Hold until bootloader completes
Product Overview
Action
Activates the LEDs for 60 seconds,
then returns the LEDs to Off State.
System LED dims but does not turn
off.
Toggle between "Stat" and "Speed"
LED modes. These modes only
affect the port data LEDs.
Stops autoboot and remains at
bootloader prompt.
