Switch Installation
Flexible Mounting
Maintain 3-inch of space to any surface above the flex mount to allow proper cooling.
Warning
Figure 33: Inserting switch into flexible mount assembly
Top Vertical Mount with two Flexible Mounts
Use the following procedure to attach two flexible mounts together.
Catalyst Digital Building Series Switch Hardware Installation Guide
49
