Installing a Compact Switch

Installing the Power Cord Retainer (Optional)

Note
Before you begin
• The power cord retainer (C9K-CMPCT-PWR-CLP) is optional. You can order it when you order your
Procedure
Step 1
Fix the power cord retainer strap to the switch using the M3 pan-head screw provided.
Figure 24: Attaching the Power Cord Retainer Strap
1
Step 2
Slide the retainer clamp around the AC power cord and position it closest to the connector on the adapter.
Note
This section applies to switches with an AC power connector.
switch, or you can order it later from your Cisco representative.
M3x6mm pan-head screw
Depending on the width of the power cord, adjust the size of the retainer clamp, if required.
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide

Installing the Power Cord Retainer (Optional)

2 Power cord retainer strap
