Rack Mounting
Step 2
Plug country-specific power cords to power connectors on the rack mount chassis. Plug the other ends of the
power cords to a power source.
Figure 47:
1
Step 3
Slide the switches into each of the rack unit slots in a front-mounting position and secure them to the rack
using the supplied screws as shown in the figure.
Catalyst Digital Building Series Switch Hardware Installation Guide
70
IEC C14 power connector
