Switch Installation
• Review the following illustrations and tables.
Figure 19: Mounting Bracket Detail
1
2
3
1/4" hole for attaching to strut channel
3/8" hole for attaching to strut channel
Mounting screw holes
Catalyst Digital Building Series Switch Hardware Installation Guide
Flexible Mounting
