Product Overview
This figure shows the switch LEDs and the Mode button that you use to select a port mode.
Figure 4: Switch LEDs and Mode Button
1
2
3
4
Downlink Port PoE LEDs
Downlink Port Data LEDs
Uplink Port Data LEDs
SPEED LED
Catalyst Digital Building Series Switch Hardware Installation Guide
5
STATUS LED
6
MODE button
7
POWER SAVE LED
8
SYSTEM LED
LEDs
7
