Installing the Power Cord Retainer
Step 4
Slide the retainer through the other latches to lock it.
Figure 53: Locking the Retainer (5RU 19" Rack Mount Chassis)
Figure 54: Locking the Retainer (Flexible mount with IEC C14 power junction box)
1
2
Catalyst Digital Building Series Switch Hardware Installation Guide
78
AC power cord
Smaller sleeve for thin power cords
3
Latch
Switch Installation
