3.16 Serial peripheral interface (SPI)/Inter-integrated sound
interfaces (I
Up to two SPIs are able to communicate up to 18 Mbits/s in slave and master modes in full-
duplex and half-duplex communication modes. The 3-bit prescaler gives 8 master mode
frequencies and the frame size is configurable from 4 bits to 16 bits.
One standard I
can operate as master or slave at half-duplex communication mode. It can be configured to
transfer 16 and 24 or 32 bits with 16-bit or 32-bit data resolution and synchronized by a
specific signal. Audio sampling frequency from 8 kHz up to 192 kHz can be set by an 8-bit
programmable linear prescaler. When operating in master mode, it can output a clock for an
external audio component at 256 times the sampling frequency.
Refer to
Hardware CRC calculation
Rx/Tx FIFO
NSS pulse mode
I2S mode
TI mode
1. X = supported.
26/117
Table 10. STM32F042x USART implementation (continued)
USART modes/features
2
S)
2
S interface (multiplexed with SPI1) supporting four different audio standards
Table 11 for the differences between SPI1 and SPI2.

Table 11. STM32F042x SPI/I2S implementation

SPI features
(1)
(1)
