Switching on and preparing for commissioning
4.7 Introduction to the onboard assistants
How can I use the assistants?
38
Status indicators:
Completed task
Current task
Partially completed task group
Uncompleted task
Press one of the three softkeys to access the corre-
sponding assistant
Press to start the assistant
Press to return to the main screen of the onboard as-
sistants
Press any operating area key (CUSTOM excluded) to
exit the main screen of the onboard assistants and
enter the corresponding operating area
Press to enter the current task or a task that is prior to
the current task
Note: This softkey becomes active when you move the
cursor key to a valid task.
