ADASH Ltd.
was). If you want to save results to the memory and not to watch them on the screen, then select fast mode.
The analyzing time will be much faster then 300 sec.
Record Analysis Start
selected for analysis.
It would be better to use example for explanation. E.g. we use record which length is 60 sec. We define time
signal measurement which length is 8 sec. It means when we push Start button, the reading takes 8 sec and
position of cursor moves of 8 sec in record.
continue
the next reading will start on the end of last reading
begin
the next reading will start on the beginning of record
again
the next reading will start on the beginning of last reading
ask
the user select any option before the reading
IMPORTANT : when you moved the cursor manually, the the next reading will always start from that position.
Appearance
Background Color
own colors profile. Use the create item below the black and white. The col.cpy will be creted on VA4_DISC.
You can change the RGB value of all colors and then save it with new name. When the instrument is switched
on, then all cpy profiles are moved to the instrument and then used. You will find your new name in the list of
Background Colors. Use the Delete button for removing of user defined colors.
Button Text Color
Runup
Contains runup global parameters.
Max Memory Size[MB]
measured data exceeds the value, then data are saved and new runup is opened.
Time Unit
days, hours, minutes
Length
undef, value
contains defined length.
Trend Time Axe
relative
real time
For further technical and contact information visit www.adash.eu, email: info@adash.cz
continue, begin, again, ask
black, white
black, white
value
If defined, then measured data are saved to individual files, where each file
the time axe begins from zero
the time of measurement is displayed on time axe
these options are used when the record is
setting of background and other colors. You can create your
It enables partial savings of runup measurement. If the size of
The unit of Length parameter (see next line).
27
Adash 4400 – VA4Pro
