F
IGURE
12) Unscrew the captive screws to inserts the thermocouple wires/ U - Lugs into it.
13) Fix the thermocouple 'U' Lugs into screw terminals. Each channel has S,+ & - signals screws ('S'
for Shield, '+' for Positive input, '-' for Negative input). Refer the below channel layout diagram of
screw terminals.
42
2-3-2: RX10 CHANNEL SCREW TERMINAL PLATE VIEW
XX
EX10xxA Preparation for Use
