VTI Instruments Corp.
EX10SC S
PECIFICATIONS
N C
UMBER OF HANNELS
D
IMENSIONS
I P
NPUT OWER
Input voltage/frequency
P C
OWER ONSUMPTION
Without modules
Fully populated with modules
A
CCESSORIES
C
ABLE
Description
VTI part number
M C
ATING ONNECTORS
Description
VTI part number
Mfg part number
S
CREWDRIVER
Description
Mfg part number
T K
ABLETOP IT
Description
VTI part number
R O
ACKMOUNT PTIONS
Description
VTI part number
Description
VTI part number
292
EX10SC G S
ENERAL PECIFICATIONS
16
1.75" H x 17.94" W x 7.75" D
90 V ac – 264 V ac*, 50 Hz/60 Hz (nominal ac)
3 VA
30 VA maximum
Cable, EX10SC-CBL01, EX10SC to EX10xxA
70-0397-000
Connector, terminal block, screw, 4-position (supplied with EX10SC)
27-0400-004
RIA Connect 31169104
Screwdriver for use with 27-0400-004
RIA Connect 791989
Table top kit for EX10XXA series
70-0355-902
Rackmount kit for EX10xxA series
70-0355-900
Rackmount slide rails
EX10SC-RK001
EX10SC Signal Conditioning
