VTI Instruments Corp.
EX10SC-8B33- S
XX PECIFICATIONS
D
ESCRIPTIONS
EX10SC-8B33-03
EX10SC-8B33-04
EX10SC-8B33-05
F R
REQUENCY ANGE
A
CCURACY
I
SOLATION
I O P
NPUT VERLOAD ROTECTED
Peak AC and DC
Continuous
T P
RANSIENT ROTECTION
CMR (C M R
OMMON ODE EJECTION
50 Hz or 60Hz
296
0 V to 10 V rms
0 V to 100 V rms
0 V to 300 V rms
45 Hz to 1000 Hz (extended range to 10 kHz)
Compatible with standard current and potential transformers
±0.25% factory
1500 V rms transformer
350 V rms maximum
2 A rms
ANSI/IEEE C37.90.1
)
120 dB
EX10SC Signal Conditioning
