Vtex10Xxa_Get_Vtb_Output_Enable - VTI Instruments EX1000A User Manual

F P
UNCTION ROTOTYPE
ViStatus vtex10xxA_get_vtb_output_enable(ViSession vi, ViPInt32 out_enable);
F P
UNCTION ARAMETERS
vi = contains a session handle to the instrument. This handle is obtained by the function and remains valid until the
session is closed.
out_enable = an integer output value in decimal that represents the output enable state of the 8-bit port. Within the
8-bit field, the MSB corresponds to LXI Trigger Bus (VTB) channel 7 and the LSB corresponds to LXI Trigger Bus
(VTB) channel 0. Valid return values: 0 through 255.
D I R V
ATA TEM ESET ALUE
Not applicable to this function.
D
ESCRIPTION
This function returns the output enable state of the trigger bus.
E
XAMPLE
// query status of VTB bit 4
ViInt32 vtb_out;
ViInt32 vtb_outen;
vtex10xxA_get_vtb_output(vi, &vtb_out);
vtex10xxA_get_vtb_output_enable(vi, &vtb_outen);
if (vtb_out & 0x10)
printf("Bit 4 is set high");
else printf("Bit 4 is set low");
if (vtb_outen & 0x10)
printf("Bit 4 is enabled");
else printf("Bit 4 is not enabled");
EX10xxA Function Calls

vtex10xxA_get_vtb_output_enable

www.vtiinstruments.com
199
