Error Code Error Message
0xBFFC0902L #define VTEX10XXA_ERROR_INVALID_TRIG_INF_VALUE
0xBFFC0903L #define VTEX10XXA_ERROR_INVALID_ARM_INF_VALUE
0xBFFC0904L #define VTEX10XXA_ERROR_INVALID_NUM_SCANS
0xBFFC0905L #define VTEX10XXA_ERROR_READ_FIFO_TIMEOUT
0xBFFC0906L #define VTEX10XXA_ERROR_STRMING_DATA_ENABLED
0xBFFC0907L #define VTEX10XXA_ERROR_ENABLING_STRMING_DATA
0xBFFC0908L #define VTEX10XXA_ERROR_STRMING_DATA_NOT_ENABLED
0xBFFC0909L #define VTEX10XXA_ERROR_DISABLING_STRMING_DATA
0xBFFC090AL #define VTEX10XXA_ERROR_INSUFFICIENT_FIRMWARE_REV
0xBFFC090BL #define VTEX10XXA_ERROR_VXI_11
0xBFFC090CL #define VTEX10XXA_ERROR_INVALID_FILTER_FREQ
0xBFFC090DL #define VTEX10XXA_ERROR_STRMIN_ALREADY_ENABLED
0xBFFC090EL #define VTEX10XXA_ERROR_INVALID_NUM_ENTRIES
0xBFFC090FL #define VTEX10XXA_ERROR_NEGATIVE_TIME
0xBFFC0910L #define VTEX10XXA_ERROR_DEVICE_LOCKED
0xBFFC0911L #define VTEX10XXA_ERROR_DEVICE_NOT_LOCKED
0xBFFC0912L #define VTEX10XXA_ERROR_CALIBRATION_IN_PROGRESS
0xBFFC0913L #define VTEX10XXA_ERROR_CALIBRATION_MISSING
0xBFFC0914L #define VTEX10XXA_ERROR_TRIGGER_SYSTEM_ERROR
0xBFFC0915L #define VTEX10XXA_ERROR_INSUFFICIENT_UPTIME
0xBFFC0916L #define VTEX10XXA_ERROR_OUT_OF_LINK_IDS
0xBFFC0917L #define VTEX10XXA_ERROR_INVALID_LINK_ID
0xBFFC0918L #define VTEX10XXA_ERROR_DUPLICATE_SCANLIST_CHNL
0xBFFC0919L #define VTEX10XXA_ERROR_SELF_CAL_MISSING
0xBFFC091AL #define VTEX10XXA_ERROR_UNKNOWN_FIRMWARE_ERROR
0xBFFC091BL #define VTEX10XXA_ERROR_INVALID_DIO_LIMIT
0xBFFC091CL #define VTEX10XXA_BOOLEAN_OUTA_RANGE
0xBFFC091DL #define VTEX10XXA_NOT_A_VALID_RSRC
0xBFFC091EL #define VTEX10XXA_ERROR_ALREADY_LOCKED_U
0xBFFC091FL #define VTEX10XXA_ERROR_ALREADY_LOCKED_NU
0xBFFC0920L #define VTEX10XXA_ERROR_ALREADY_UNLOCKED
0xBFFC0921L #define VTEX10XXA_ERROR_NONVOL_SELF_CAL_MISSING
0xBFFC0922L #define VTEX10XXA_ERROR_FIFO_EMPTY
0xBFFC0923L #define VTEX10XXA_ERROR_STRING_TOO_BIG
0xBFFC0924L #define VTEX10XXA_ERROR_PTP_NOT_RUNNING
0xBFFC0925L #define VTEX10XXA_ERROR_INVALID_BOOLEAN_VALUE
0xBFFC0926L #define VTEX10XXA_ERROR_WIREDOR_MUST_BE_SET
0xBFFC0927L #define VTEX10XXA_ERROR_INVALID_TIMER_COUNT
0xBFFC0928L #define VTEX10XXA_ERROR_INVALID_TIMER_TIME
0xBFFC0929L #define VTEX10XXA_ERROR_INVALID_LAN_SOURCE
0xBFFC092AL #define VTEX10XXA_ERROR_INVALID_LAN_EVENT_DOMAIN
0xBFFC092BL #define VTEX10XXA_ERROR_INVALID_LAN_EVENT_EVENTID
0xBFFC092CL #define VTEX10XXA_ERROR_INVALID_LAN_EVENT_FILTER
0xBFFC092DL #define VTEX10XXA_ERROR_INVALID_OP_WHILE_LOG_ENABLED
0xBFFC092EL #define VTEX10XXA_ERROR_PPS_REQUIRES_DIO0_OUTPUT_LOW
0xBFFC092FL #define VTEX10XXA_ERROR_GAIN_OUT_OF_RANGE
0xBFFC0930L #define VTEX10XXA_ERROR_OFFSET_OUT_OF_RANGE
0xBFFC0931L #define VTEX10XXA_ERROR_INVALID_CORRECTION_LIST_LENGTH
0xBFFC0932L #define VTEX10XXA_ERROR_INVALID_GAIN_LIST_LENGTH
0xBFFC0933L #define VTEX10XXA_ERROR_OPERATION_VALID_ONLY_ON_VOLT_CH This operation is only valid on general purpose
0xBFFC0934L #define VTEX10XXA_ERROR_INVALID_EVENTLOG_OVERFLOWMODE
0xBFFC0935L #define VTEX10XXA_ERROR_INVALID_CAL_FILE_TYPE
0xBFFC0936L #define VTEX10XXA_ERROR_ACQUISITION_IN_PROGRESS
0xBFFC0937L #define VTEX10XXA_ERROR_FACTORY_MODE_ONLY
0xBFFC0938L #define VTEX10XXA_ERROR_CAL_FILE_TOO_LARGE
EX10xxA Function Calls
www.vtiinstruments.com
Meaning
Invalid trigger infinite value.
Invalid arm infinite value.
Invalid number of scans.
Timeout on read FIFO.
Streaming data already enabled.
Enabling streaming data failed.
Streaming data not enabled.
Disabling streaming data failed.
Insufficient firmware revision.
VXI-11 Error.
Invalid filter frequency.
Streaming data already enabled on instrument.
Invalid number of entries.
Illegal negative time.
Device locked.
Device not locked.
Calibration in progress.
Calibration missing.
Trigger system error.
Insufficient uptime for requested operation.
Maximum number of link IDs exceeded.
Invalid link ID.
Duplicate channel In scanlist.
Self-calibration missing.
Unknown firmware error.
Invalid DIO limit value.
Out of range Boolean value.
Not a valid resource string.
Instrument already locked by this host.
Instrument already locked by another host.
Instrument is not locked at this time.
Nonvolatile self calibration data missing.
FIFO is empty.
Input buffer contains too many characters.
Precision time protocol not running. Try
reconfiguring time settings, or a power cycle.
Invalid Boolean value.
Wired-OR must be set.
Invalid timer count.
Invalid time setting.
Invalid LAN source.
Invalid LAN domain.
Invalid LAN Event ID.
Invalid LAN filter.
This operation is not valid while LAN event
logging is enabled.
PPS enable requires DIO0 output to be enabled
and low.
Linear correction gain value out of range.
Linear correction offset value out of range.
Linear correction list length must be the same as
channel list length.
Gain list length must be the same as channel list
length.
voltage channels.
Invalid event log overflow mode.
Invalid calibration file type.
Acquisition in progress.
Only works when calFileType parameter is a
value greater than 0.
Unable to load the entire calibration file into
memory.
