API
vtex10xxA_get_system_time
vtex10xxA_get_trig_lan_eventID
vtex10xxA_get_trig_lan_filter
vtex10xxA_get_trigger_count
vtex10xxA_get_trigger_delay
vtex10xxA_get_trigger_infinite
vtex10xxA_get_trigger_source
vtex10xxA_get_trigger_sourceEx
vtex10xxA_get_trigger_timer
vtex10xxA_get_user_cjc_enable
vtex10xxA_get_user_cjc_temp
vtex10xxA_get_user_conversion
vtex10xxA_get_vtb_input
vtex10xxA_get_vtb_output
vtex10xxA_get_vtb_output_enable
vtex10xxA_get_vtb_wiredor
vtex10xxA_get_vtb_wiredor_bias
vtex10xxA_init
vtex10xxA_init_imm
vtex10xxA_lock
vtex10xxA_pop_logged_LAN_event
vtex10xxA_read_fifo
vtex10xxA_read_fifoEx
vtex10xxA_reset
vtex10xxA_reset_fifo
vtex10xxA_reset_trigger_arm
vtex10xxA_revision_query
vtex10xxA_self_cal_clear
vtex10xxA_self_cal_clear_stored
vtex10xxA_self_cal_get_status
vtex10xxA_self_cal_init
vtex10xxA_self_cal_is_stored
vtex10xxA_self_cal_load
vtex10xxA_self_cal_store
vtex10xxA_self_test
vtex10xxA_self_test_init
vtex10xxA_set_alarm
vtex10xxA_set_alarm_enable
vtex10xxA_set_arm_count
vtex10xxA_set_arm_delay
vtex10xxA_set_arm_infinite
vtex10xxA_set_arm_lan_eventID
EX10xxA Function Calls
www.vtiinstruments.com
Description
Returns the instrument's current time in seconds.
Returns the event ID of a LAN trigger event.
Returns the filter for a LAN trigger event.
Returns the trigger count value.
Returns the trigger delay.
Returns the enabled status of an infinite trigger
count.
Returns the trigger source excluding LAN events.
Returns the trigger source including LAN events.
Queries the timer interval for the timer source
event.
Returns the enabled status of a user-defined CJC
temperature of a specified channel.
Returns the user-defined CJC temperature of a
specified channel.
Returns the user-defined conversion polynomials.
Returns the current input state of the trigger bus.
Returns the programmed output state of the trigger
bus.
Returns the output enable state of the trigger bus.
Returns the Wired-OR state for each LXI Trigger
Bus channel.
Returns the Wired-OR bias enable state for each
LXI trigger bus channel.
Opens an instrument programming session.
Performs a trigger initialize.
Attempts to acquire a lock on the instrument.
Returns an oldest event log entry in the
instrument.
Retrieves acquisition data.
Retrieves acquisition data with timestamps and
CJC data.
Performs an instrument reset.
Clears the FIFO memory.
Performs a reset of the trigger configuration
parameters.
Returns the release revision of the instrument
driver and embedded firmware.
Clears the current self cal data.
Clears self cal data from nonvolatile memory.
Returns the completion status of self-calibration.
Performs an instrument self-calibration.
Returns the presence of self cal data in nonvolatile
memory.
Loads nonvolatile self cal data as the current self
cal data.
Stores the current self cal data into nonvolatile
memory.
Performs a self-test in synchronous mode.
(Currently supported only in RX10xx.)
Performs a self test operation in asynchronous
mode. (Currently supported only in RX10xx.)
Sets the alarm time, period, and count for the LXI
alarm source event.
Enables or disables the use of the LXI alarm.
Sets the arm count value.
Sets the arm delay.
Enables or disables the use of an infinite arm
count.
Sets the event ID of LAN arm event.
