VTI Instruments EX1000A User Manual page 297

EX10SC-8B35-04 S
PECIFICATIONS
D
ESCRIPTION
I R L
NPUT ANGE IMITS
I R
NPUT ESISTANCE
Normal
Power Off
Overload
I P
NPUT ROTECTION
Continuous
Transient
S E C
ENSOR XCITATION URRENT
L R E
EAD ESISTANCE FFECT
CMV (C M V
OMMON ODE OLTAGE
Input to output
T
RANSIENT
Input to output
CMR (C M R
OMMON ODE EJECTION
50 Hz or 60Hz
NMR (N M R
ORMAL ODE EJECTION
S
TABILITY
Offset
Gain
N
OISE
Output, 100 kHz
B (-3 dB)
ANDWIDTH
R T
ESPONSE IME
90% span
100 Ω P
T
Input range
Accuracy
RTD S
TANDARDS
100 Ω Pt
Alpha coefficient
DIN
JIS
IEC
EX10SC Signal Conditioning
4-wire 100 Ω RTD (0 °C to 600 °C)
-200 °C to +850 °C (100 Ω Pt)
50 MΩ
200 kΩ
200 kΩ
240 V ac
ANSI/IEEE C37.90.1
0.25 mA
±0.005 °C/Ω
)
1500 V rms maximum
ANSI/IEEE C37.90.1
)
120 dB
)
70 dB at 60 Hz
±20 ppm/°C
±50 ppm/°C
200 μV rms
3 Hz
150 ms
0 °C t o +600 °C (+32 °F to +1112 °F)
±0.45 °C
0.00385
DIN 43760
JIS C 1604-1989
IEC 751
