EX10SC-8B36-04 S
PECIFICATIONS
D
ESCRIPTION
I R
NPUT ANGE
I R
NPUT ESISTANCE
Normal
Power off
Overload
I P
NPUT ROTECTION
Continuous
Transient
S E C
ENSOR XCITATION URRENT
100 Ω, 500 Ω, 1 kΩ sensor
10 kΩ sensor
L R E
EAD ESISTANCE FFECT
100 Ω, 500 Ω, 1 kΩ sensor
10 kΩ sensor
CMV (C M V
OMMON ODE OLTAGE
Input to output
T
RANSIENT
Input to output
CMR (C M R
OMMON ODE EJECTION
50 Hz or 60Hz
NMR (N M R
ORMAL ODE EJECTION
A
CCURACY
L
INEARITY
S
TABILITY
Offset
Gain
N
OISE
Output, 100 kHz
B (-3 dB)
ANDWIDTH
R T
ESPONSE IME
90% span
EX10SC Signal Conditioning
Potentiometer input (0 Ω to 10 kΩ)
0 to 10 kΩ
50 MΩ
200 kΩ
200 kΩ
240 V ac
ANSI/IEEE C37.90.1
0.25 mA
0.10 mA
±0.01 Ω/Ω
±0.02 Ω/Ω
)
1500 V rms maximum
ANSI/IEEE C37.90.1
)
120 dB
)
70 dB at 60 Hz
±0.05% span
±0.02% span
±20 ppm/°C
±50ppm/°C
200 μV rms
3 Hz
150 ms
