Replacing The Back Panel Assembly - Respironics DreamStation Service & Technical Reference Manual

P 7-8
AGE
7.1.5 R
EPLACING THE
Kit
Back Panel Assembly
T B
O REMOVE THE ACK
1. Remove the Water Chamber Assembly (refer to previous corresponding section).
2. Pull the Back Panel away from the Humidifier while lifting up on the top to release the Back Panel
tab from the latch area.
T B
O INSTALL THE ACK
1. Align the Back Panel onto the Bottom Assembly.
2. Secure the Back Panel with the four # 4 x 1/2" screws (torque to 6 IN-LB).
3. Verify the Back Panel is fully seated/secure.
B P A
ACK ANEL SSEMBLY
•
Back Panel Assembly
•
# 4 x 1/2" screws (qty 5)
P A :
ANEL SSEMBLY
Torque screws to 6 IN-LB
when installing Back Panel
F 7-10: B
IGURE
P A :
ANEL SSEMBLY
Included in Kit
P A
ACK ANEL SSEMBLY
1117539, V
Tools Required
•
Torx Screwdriver (T10 is
recommended)
. 07
ER
