Advanced Operation

5
5.1

Chapter Overview

This chapter describe how to use the Strata RX Configurator
software to configure settings in the Strata RX. This is
information that would be useful to technical staff.
Settings that are made using the front panel controls are covered
in Chapter 3, "Routine Operation".
For a summary of what settings can be made with the front panel
Control Switch and which are made using the Configurator, see
Section 5.6 on page 5-18.
Here are the topics covered:

Before You Begin

RX System

RX Configurator

Settings

System Rules
Creating a Configuration
Creating a New Configuration Offline
Loading a Configuration From a File
Loading a Configuration From the RX
Saving the Configuration to a File
Programming the Configuration Into the RX
Monitoring the Radio
Front Panel vs. Configurator Settings
