Replacement Parts

8
8.1

Chapter Overview

This chapter describes which replacement parts are available for
the Strata RX.
Since there are no supported field repairs on the RXU or
RCU, the only parts available are external cables and
mounting hardware.
8.2

External Cables

The external cables for the Strata RX are listed in Table 8-1. If
you need something that is not listed, ask your Sales
Representative or consult the factory.
Table 8-1: Strata RX Cables
Description Part Number
AC Power Cable 841915-1
(115 VAC)
842066-1
(2130 VAC)
DC Power Cable 907481-1
(3' / 1m long)
907481-2
(10' / 3 m long)
Power Input 52155-37
Connector
Strata RX Technical Reference Manual
Comments
Provides AC Mains Power
to the ACU Power Supply.
Connects the RXU or RCU
to the ACU Power Supply.
Connectors on both ends.
Connector only.
Replacement Parts
Table 8-1: Strata RX Cables
Description Part Number
Audio Output Cable 907471-2
Null Modem Cable 56500-108
Multipurpose Data 907854-1
Cable
RF Connection 800192-24
Cable
Comments
Splits output from AUDIO
connector into 4 XLR
connectors. See
Section 6.8 on page 6-7.
Connects RS-232 port on
RX to PC. For
Programming and
Monitoring Data only. See
Section 6.10 on page 6-
12.
Connects RS-232 port on
RX to PC. For both
Programming and
Monitoring Data, and
Wayside Data. See
Section 6.10 on page 6-
12.
Connects Signal Output of
RXU to Signal Input of
RCU.
8-1
