6.9

Signal Connections

The details of the many signal connections on the RXU and RCU
are given in Table 6-4.
Table 6-4: Signal Connections
Function Connector
RF Input 50 ohm
(RXU only) "N"-type
Gen Lock 75 ohm BNC
Monitor 75 ohm BNC
(MON.)
Signal Output 75 ohm BNC
Signal In 75 ohm BNC
(RCU only)
Strata RX Technical Reference Manual
Notes
Amplitude should be less than
-25dBm. Stronger signals will
overload RXU and degrade system
performance.
Amplitude should be 400 mV peak-
peak, nominal.
Output can be configured to be
either ASI or 70 MHz IF depending
on installed hardware and operating
mode chosen.
Output may be 70 MHz IF, analog
video, digital ASI, or digital SDI
depending on installed hardware
and operating mode chosen.
70 MHz IF is at 0 dBm.
Input is 70MHz IF from RXU or
other RF front end. Input level
should be -10 dBm.
6.10

Data Connections

Both the RXU and RCU have RS-232 data connections. On the
RXU the RS-232 connector is on the rear panel; on the RCU it is
on the front panel.
These female DB-9 connectors are used for three purposes:
• Remote Control using the Strata RX Remote Control
Panel.
• Radio Programming and Monitoring using a PC.
• Wayside Data communication.
The RX can be connected directly to a PC, or it can be interfaced
to a LAN for applications such as remote monitoring and control.
6.10.1

Remote Control

The RX can be controlled from a remote location using the Strata
RX Remote Control Panel. This is typically used for installation in
an aircraft, where the Remote Control is mounted in a cockpit
instrument panel and the RX is in another compartment.
The RX connects to the Remote Control Panel using a standard
null modem cable. One cable is supplied with each Remote
Control Panel ordered. Additional cables can be purchased from
Vislink (part number 56500-108) or at any computer or
electronics store.
For details on installing the Remote Control Panel and
connecting it to the RX, refer to the RX Remote Control Panel
Operatorís Guide (Vislink part number 400497-1).
6.10.2

Radio Programming and Monitoring

This is used when programming or monitoring the radio using the
RX Configurator software running on a Windows PC.
Installation 6-12
