CAUTION
Power supply cords and cables must be
protected. Do not run cords where they can
be walked upon. Protect cables against
pinching and chafing. Pay special attention
to locations where the cables enter or exit
an enclosure or make a sharp bend.
CAUTION
Ensure that the electrical supply is protected
by overcurrent protection devices as
required by the applicable electrical codes.
WARNING
Be sure the power being supplied matches
the power required by the equipment.
6.7

Grounding

The mounting bracket and equipment must be connected to the
common ground on the installation. This common ground is often
the vehicle or aircraft ground. The ground wire should be as
short as possible, and follow the straightest path possible.
CAUTION
Be sure the equipment grounding follows
applicable electrical codes.
CAUTION
Never modify a grounded power plug to
connect to an ungrounded receptacle.
Strata RX Technical Reference Manual
6.8

Audio Connections

The Strata RX can provide Analog Audio Output or Digital
Audio Output, depending on how the RX is configured. All audio
outputs appear on the same panel connector.
The functions of some of the pins will change between
analog output and digital output. You'll need to plan your
usage in advance and complete your audio wiring accordingly.
See Sections 6.8.2 and 6.8.3.
6.8.1

Panel Connections

The RXU and RCU both use the same type of audio connector.
In the RXU it is on the front panel; on the RCU it is on the rear
panel. In both cases it is labelled "AUDIO".
The mating connector that plugs into this panel connector is
described below.
Manufacturer:
Part Number
Description:
See Figure 6-8 for pin designations on the panel connector.
Installation
Amphenol (or ITT Cannon)
MS3116F12-10S (KPT06F12-10S)
10-pin female, cable-mount.
6-7
