Mounting Hardware

The mounting hardware for the Strata RX is listed inTable 8-2. If
you need something that is not listed, ask your Sales
Representative or consult the factory.
Table 8-2: Strata RX Mounting Hardware
Description Part Number
Antenna Lock Plate 841199-1
Universal Mounting 907516-1
Bracket
Aircraft Mounting 907739-1
Bracket
Fixed Mounting 907211-1
Bracket
Quick Release 907559-1
Strata RX Technical Reference Manual
Comments
For attaching MRC
antenna directly to RF
Input of RXU.
For mounting to a tripod.
Each bracket accepts 1
unit (RXU or RCU).
For mounting in an aircraft
instrument panel. Each
bracket accepts 2 units
(RCU and RXU). Includes
bracket, mounting
hardware.
For mounting to a floor or
bulkhead. Each bracket
accepts 2 units (RCU and
RXU). Bracket only.
For mounting on a tripod.
Replacement Parts 8-2
