Configurator Reference

C
C.1 Appendix Overview
This appendix provides detailed information on how to install and
operate the Strata RX Configurator software.
The topics covered in this Appendix are listed below.
Topic

Configurator Overview

Working With the Configurator

Configurator Pages
Front Panel vs. Configurator
Settings
Configurator Troubleshooting
Installing the Configurator
PC Requirements
RX System Compatibility
C.2 Configurator Overview
The Strata RX Configurator is a Windows-based application that
enables you to control all of the settings on the Strata RX, and
tailor them exactly to your needs.
Settings can be configured offline (not connected to an RX), or
you can connect to the RX through an RS-232 link to make the
changes. Either way, the configuration can be saved to a file and
later recalled.
Strata RX Technical Reference Manual
Page
C-1
C-1
C-6
C-14
C-17
C-21
C-22
C-22
Configurator Reference
In addition, the Configurator allows you to monitor the RX from
your PC, in near-real time, and to log the information to a file.
C.3 Working With the Configurator
This section provides details of how to interact with the
Configurator and its Pages, Tabs, Buttons, and menus
Here are the topics covered:
Topic

Tabs, Pages and Buttons

Progress Bars
Load and Program Options
C.3.1 Tabs, Pages and Buttons
The Strata RX Configurator has an easy-to-use graphical user
interface. The settings are grouped into Pages according to
function. The Pages are accessed using Tabs along the bottom
of the screen. Pages also contain Buttons to activate different
functions.
Page
C-1
C-3
C-4
