Vislink Strata RX Technical Reference Manual page 105

Table 6-2: Audio Connections - Analog Audio Output
Panel
Connector Function
Pin
Audio A
A Right (return)
B Ground
C Right (live)
D Left (return)
B Ground
E Left (live)
Audio B
F Right (return)
G Ground
H Right (live)
J Left (return)
G Ground
K Left (live)
Strata RX Technical Reference Manual
Analog Mode
Controlled by "Audio 1" in
Configurator, displayed as
"Audio 1" in Monitor
Screens.
Controlled by "Audio 2" in
Configurator, displayed as
"Audio 2" in Monitor
Screens.
Controlled by "Audio 3" in
Configurator, displayed as
"Audio 3" in Monitor
Screens.
Controlled by "Audio 4" in
Configurator, displayed as
"Audio 4" in Monitor
Screens.
Installation
Digital Mode
Controlled by "Audio A" in
Configurator, displayed as
"Audio A" in Monitor
Screens.
Controlled by "Audio B" in
Configurator, displayed as
"Audio B" in Monitor
Screens.
Audio Cable
XLR Connector Pin Number
Audio 1
Audio 2
Audio 3
Audio 4
3
1
2
3
1
2
3
1
2
3
1
2
6-9
