Vislink Strata RX Technical Reference Manual page 111

Figure 6-12: Radio and Wayside Data Connections
Radio Data
Wayside
Data
Figure 6-13: Multipurpose Radio and Wayside Data Cable
To Radio
RS-232 Panel
Connector
Strata RX Technical Reference Manual
Strata RX Data Port
DB9 Male
2
Radio data from external computer
RD
3
Radio data to external computer
TD
5
SG
SG
7
Wayside data to external device
TD
8
Wayside data from external device - not used
RD
Cable-mount
DB9 Female
2
3
5
7
8
Receive Data
Transmit Data
Signal Ground
Transmit Wayside Data
Receive Wayside Data
Cable-mount
DB9 Male
2
3
5
2
3
5
Cable-mount
DB9 Female
Installation
Radio Data
Wayside Data
6-15
