Setting the COFDM Bandwidth

The COFDM Bandwidth must be set to match the bandwidth
used by the transmitted signal. The RX will not automatically
set this parameter.
COFDM Bandwidth only operates when the RX is operating in
Digital mode.
To set the COFDM Bandwidth, follow these steps:
Be sure Strata is connected and
powered. See "Setting Up" and
"Turning the power ON and OFF".
Start at the Main Screen.
Preset #3
-43.2 dBm
Turn the Control Switch LEFT until the
display reads
Set OFDM BW.
Push the Control Switch to select
Set OFDM BW.
Bandwidth setting begins to blink.
Turn the Control Switch LEFT until the
desired Bandwidth is displayed.
The choices are:
• 6 MHz
• 7 MHz
• 8 MHz
Strata RX Operator's Guide/Tech Ref Manual
The current
Push the Control Switch to select that

Bandwidth.

Display indicates the new setting,
then changes back to the Main
Screen after the default delay.
Routine Operation 3-25
