power supply or from another source such as aircraft or vehicle
power.
Power is distributed to the RX in one of two ways: through the
front panel connectors on both the RXU and RCU, or over the
coaxial cable connecting the RXU and RCU.
Which method you use will depend on whether the RXU and
RCU are located together ("co-located") or are in separate
locations.
RXU and RCU Co-Located If the RXU and RCU are
co-located, power is usually supplied to each unit through its
power connector, from the same power source. See Figure 6-4.
Figure 6-4: Powering the RXU and RCU Independently
Strata RXU
Power
Cable
DC Power (+10.5 V - +36 V)
RXU and RCU Separated If your installation calls for
separating the RXU and RCU, the RXU can be powered by DC
supplied by the RCU via the coaxial cable between the units.
See Figure 6-5.
Strata RX Technical Reference Manual
Strata RCU
Power
Cable
Figure 6-5: Powering the RXU from the RCU
Strata RXU
WARNING
Panel Power Connections The RXU and RCU use the same
type of power connector. In the RXU it is on the front panel; on
the RCU it is on the rear panel. In both cases it is labelled
"POWER".
The mating connector that plugs into this panel connector is
described below.
Manufacturer:
Part Number
Description:
See Figure 6-6 for pin designations on the panel connector. The
mating connector is shown in Figure 6-7.
See Table 6-1 for connections.
Installation
Coax
up to 600'
(200 m)
DC Power (+10.5 V - +36 V)
Turn off DC Power on the coax before
connecting any test equipment.
ITT Cannon
KPT06F12-8S
8-pin female, cable-mount.
Strata RCU
Power
Cable
