PBX 1
L1 master
L2 master
L3 master
Direct connection
Use the RJ45 jacks on one of the
■
external S ports for an S
0
nection between two
OpenCom 510s.
PBX 1, S ext
0
1 2 3 4 5 6 7 8
8 7 6 5 4 3 2 1
PBX 2, S ext
0
(RJ-45 socket)
Wiring of a direct connection
Connection via an Active
Transmission System
For distances exceeding the range of
a direct connection, an active trans-
mission system can increase the
range to up to 50 km. Normally the
L1 master is the transmission system
for the two connected PBXs. For the
protocol layers L2 and L3, one PBX is
normally the protocol master and
the other PBX is the protocol slave.
PBX 1
Transmission
L1 slave
System
L2 master
L3 master
L1 master
Connection by an active transmission
system
PBX Networking
Note: The active transmission sys-
PBX 2
L1 slave
tem itself gets its L1 clock either from
L2 slave
L3 slave
the network operator or from a clock
generator connected by wire.
Connection via the Public
con- Network
0
Point-to-point connections via the
public network of a network opera-
tor can be used for bridging dis-
tances beyond 50 km. Due to the
long distance involved, for technical
reasons it is not possible to synchro-
nise the L2 protocol. Consequently,
the public network is normally the
protocol master for protocol layers
L1 and L2. One PBX is therefore the
L3 master and the other PBX the L3
slave.
PBX 1
L1 slave
L2 slave
L3 master
Point-to-point connection via a pub-
lic network

Configuration

The possible configurations de-
scribed below can be set up in the
Web console using the PBX Configu-
ration: Trunks menu.
PBX 2
Trunk groups
L1 slave
L2 slave
This is a group of lines of the same
L3 slave
type and direction. A line can only be
assigned to one trunk group.
PBX 2
Public
L1 slave
network
L2 slave
L3 slave
L1 master
L2 master
PBX Networking
105
