DETEWE OpenCom 510 User Manual page 26

– clicking on Restart in the
SYS Configuration: Restart
menu in the Configurator.
2. Wait until the LEDs of the in-
stalled modules start flashing
red.
DANGER! Hazardous volt-
ages inside the device!
3. Unplug all of the mains cables of
the OpenCom 510 to disconnect
the system from the mains sup-
ply.
The central control module must
not be installed if the
OpenCom 510 is switched on!
Refer to Notes on Disconnecting
the Mains Supply starting on
page 23.
4. Remove the screws with which
the central control module is se-
cured in the 1-12 frame and pull
the module out.
5. Unpack the central control mod-
ule.
24
Installing Modules
CAUTION!
Static charge can damage elec-
tronic devices. Observe the regu-
lations regarding electrostati-
cally sensitive components.
6. Carefully push the central con-
trol module into slot 0 (see also
the illustration OpenCom 510: 1-
12 frame slots on page 22). The
printing on the front of the mod-
ule should be at the top.
Ensure that the backplane plug
of the central control module is
securely plugged into the socket
on the backplane.
7. Refit the screws to secure the
module in the 1-12 frame.
8. Plug the desired cables into the
corresponding RJ45 sockets on
the central control module. Re-
fer to Modules starting on
page 52 for information on pin
assignment.
9. Switch the OpenCom 510 on
again. To do so, reconnect the
group 1 power supply unit (see
A in the illustration
OpenCom 510: 1-12 frame slots
on page 22) with the mains sup-
ply (if you are powering the
Installation
