MS+A1-8
1 3
2 4
MS+A1-8
The LEDs indicate the following:
LED 1: Constantly yellow
LED 2: Constantly green
Flashing yellow
Constantly red
LED 3: –
LED 4: –
Operational Information
The MS+A1-8 interface card can be
exchanged during operation, i.e.
without powering down the system.
However, the slot must first be deac-
tivated in the Configurator in the
web console (see Installing Interface
Cards starting on page 25).
Modules
At least one connection established through the in-
terface card is active.
The interface card is operational; the slot has been
activated (flickering is normal).
The interface card is ready, but the slot has not been
activated or the interface card has not been config-
ured yet.
New software is being loaded onto the interface
card. If the LED lights up red for an extended period
of time, there may be a fault.
Not used
Not used
