In order to connect RFPs, U
■
ports 1+2, 3+4, 5+6 or 7+8 can
be combined by setting the DIP
switches on the card accord-
ingly.
For further information, refer to
Upn Ports starting on page 38.
The MS+UPN2-8 interface card
■
runs on software acquired from
the system. After the card has
been installed it will automati-
cally load the required software.
LED 1: Constantly yellow
LED 2: Constantly green
Flashing yellow
Constantly red
LED 3: –
LED 4: –
Modules
Pin Assignment
pn
For information on the U
pin assignment, refer to Upn Ports
starting on page 38.
Indicators
There are four LEDs on the front of
the MS+UPN2-8 interface card.
MS+UPN2-8
1
2
MS+UPN2-8
The LEDs indicate the following:
At least one connection established through the in-
terface card is active.
The interface card is operational; the slot has been
activated (flickering is normal).
The interface card is ready, but the slot has not been
activated or the interface card has not been config-
ured yet.
New software is being loaded onto the interface
card. If the LED lights up red for an extended period
of time, there may be a fault.
Not used
Not used
interface
pn
3
4
MS+UPN2-8
67
