Configuration Examples

OpenCom 510 in Computer Networks

One of the outstanding features of
the OpenCom 510 is the integration
of telephony and computer net-
works. Connect the OpenCom 510
via a computer network (LAN) with
suitably configured workstations,
and you can use its network features
from these workstations. Using a
Web browser you can access:
the OpenCom 510 Configurator
■
call charge administration
■
the OpenCTI 50, with which tele-
■
phone functions can be used on
a PC
the OpenCom 510 central tele-
■
phone book and your personal
telephone book as well as to the
Server configuration in the LAN OpenCom 510 Functions
No IP server present
IP server present
DHCP server present
IP server present
No DHCP server present
86
OpenCom 510 in Computer Networks
company telephone book (if the
multi-company variant is acti-
vated).
In addition, the OpenCom 510 can
be used as an Internet access server.
RAS access can also be implemented
using the OpenCom 510, which ena-
bles the integration of external staff
in the LAN.
In this chapter you will find several
examples of configurations showing
integration of the OpenCom 510 in a
LAN. Which example applies to your
situation depends on the size and
properties of the existing or planned
LAN infrastructure.
The following LAN prerequisites are
possible:
OpenCom 510 functions automatically as DHCP and
DNS server
OpenCom 510 functions automatically as DHCP
client
System Administrator must assign IP address and
DNS name for OpenCom 510
Special case when integrating the OpenCom 510 in
"NET Configuration: Easy
a LAN; settings in the
Access" menu
must be coordinated with the re-
sponsible system administrator
