Interfaces and Connectible
Terminals

Overview

The OpenCom 510 interfaces have
been implemented as RJ45 sockets
on the front of the interface cards
and the central control module. No
special proprietary cables are re-
quired. Patch panels can be con-
Overview: Interfaces and Interface Cards
Interface Card
S MX+S01-8
0
S MT+S2M1-1
2M
U MS+UPN1-8
pn
U MS+UPN2-8
pn
a/b MS+A1-8
PCM MC+1-3
LAN MC+1-3
COM / V.24 MC+1-3
The following terminals and systems
can be connected to the
OpenCom 510:

Interfaces and Connectible Terminals

nected by means of standard patch
cables.
For technical information on the in-
terfaces, refer to Modules starting on
page 52.
Properties
8 S interfaces for either external or inter-
0
nal connections
1 S interface for connecting to digital
2M
networks (primary multiplex connections)
or for cascading two PBXs
8 U interfaces, not DECT-capable
pn
8 U interfaces, not DECT-capable
pn
8 a/b interfaces
1 PCM port
(on central control module)
1 Ethernet port (10/100 Mbits/s)
(on central control module)
2 V.24 ports
(on central control module)
Page
63
60
65
66
68
57
57
57
33
Overview
