Technical Data

Please observe the technical infor-
mation regarding modules under
Modules starting on page 52.
Component
1-12 frame of the OpenCom 510
– BPV+1-12 backplane system:
– Dimensions:
– Number of slots:
Cascading of two 19" frames
– Length of cable:
– Number of channels:
Modules
– MPS+1-AC power supply unit (with AC/DC converter)
– MC+1-3 central control module
– MT+S2M1-1 trunk module
– MX+S01-8 subscriber or trunk module
– MS+UPN1-8 subscriber module
– MS+UPN2-8 subscriber module
– MS+A1-8 subscriber module
Technical Data
Supply voltages and system signals for up
to 2 power supply units, 1 central control
module and 12 interface cards
4.5 height units (1 U = 44.45 mm)
19" frame in accordance with DIN 41494
Part 5 for installation in a 19" cabinet
12
50 cm; 1:1 network cable connecting mas-
ter and slave
236
Page
28
–
22
98
–
55
57
60
63
65
66
68
153
